Supports multiple communication interfaces such as Ethernet, RS-232, RS-485, CAN bus, etc. Support real-time control function to ensure immediate response to devices and systems. It has data storage function and can save important data and configuration files on local or external storage devices.
Description
1、 Basic positioning and attribution
Product type: Control board/driver board module for ABB industrial automation field, suitable for medium voltage frequency converters (such as ACS880-34/ACS580MV series) or DCS/PLC systems, as the core control unit, connecting power devices with the main control system.
Application scenarios: High voltage motor speed regulation, industrial transmission systems (metallurgy, power, chemical, mining, etc.), responsible for driving signal processing, status feedback, and logic control of power modules (such as IGBT/IGCT).
2、 Core functions and features
1. Power device driver
Output precise driving pulses, control the on/off timing of IGBT/IGCT modules, and adapt to high-voltage and high-power scenarios of medium voltage inverters (such as 3kV~10kV motor drive).
Support multi-channel synchronous driving, meet the parallel/redundant requirements of frequency converter power units, and ensure stable conversion of high-voltage electrical energy.
2. Signal processing and feedback
Real time status of the power module (temperature, current, voltage, fault signals, etc.) is collected and fed back to the main control system through a high-speed bus (such as ABB customized protocol) to achieve closed-loop control.
Built in fault diagnosis logic (overcurrent, overvoltage, undervoltage, temperature abnormality, etc.), which quickly blocks the drive signal when an abnormality is triggered to protect equipment safety.
3. Industrial grade reliability design
Wide temperature working range (typical -25 ℃~+70 ℃), suitable for harsh industrial environments such as high-temperature steelmaking workshops and high dust mines.
Anti electromagnetic interference (EMC) design, certified for industrial electromagnetic compatibility (such as IEC 61800-3), to resist electromagnetic noise from the frequency converter itself and external devices.
4. System compatibility
Compatible with ABB medium voltage frequency converter platforms (such as ACS880-34 series), seamlessly collaborating with ABB main control units and power modules.
Support hot plugging (in some scenarios), facilitating quick replacement of faulty modules and reducing system downtime.
