GE DS200DCFBG2BNC is part of the Mark VI series in the GE Speedtronic control system. It has two servo outputs, I/O for six LVDT position sensors, and two active pulse rate inputs for flow monitoring.
Description
Hardware specifications:
Signal transmission interface: Send and receive input and output signals through eighteen plug connectors and nine pin connectors. The pin connectors are located in the upper left corner of the board, marked as V1 to V3, P1A, P2A, VM1A, VM1B, VB2A, and VM2BA; The plug connectors are distributed throughout the board, ranging from 2-pin male connectors to multi pin connectors.
Other components: There are seven DIP switches, five TP test points, twelve jumpers, and three fuses on the board. The fuse is used for power protection and has two LED lights and a neon indicator light to indicate the status of the fuse. DIP switches are used to select the AC line voltage and the voltage applied to the DC bridge voltage feedback VCO circuit and DC motor voltage feedback circuit. In addition, the board is equipped with seven transformers, oscillation chips, a relay, over fifty resistor network arrays, heat sinks, as well as various integrated circuits, capacitors, and resistors, using carbon composite resistors (CCR) and metal film resistors.
Product specifications:
Size: Approximately 13.3cm x 7.08cm x 3.93cm.
Weight: 1kg.
Certification: CE, UL certification.
