This relay terminal board is a critical component designed for General Electric’s Mark VI series of gas and steam turbine controls. It serves as an essential relay output terminal board that enhances the functionality and reliability of industrial automation systems.
Description
GE IS200TRLYH1BGF Relay Terminal Board
The GE IS200TRLYH1BGF is a critical Relay Terminal Board designed for industrial control systems within General Electric’s Mark VI series. This robust component ensures reliable electrical connection management in demanding environments like power generation facilities and manufacturing plants, delivering precise signal switching and load handling capabilities for continuous operation.
Technical Specifications
| Manufacturer | General Electric (GE) |
| Model | IS200TRLYH1BGF |
| Series | Mark VI |
| Dimensions | 33 cm × 17.8 cm × 5.5 cm |
| Weight | 1.42 kg |
| Terminals | 48 terminals (2 blocks × 24) |
| Relays | 6 vertical relays with transparent covers |
| Transistors | 12 transistors (6 per relay side) |
Application & Compatibility
