GE IS200TTURH1CCC is a terminal turbine plate manufactured for its Mark VI turbine control system series. There are two large transformers, eight red circular components, as well as many diodes, resistors, and capacitors on the circuit board.
Description
Appearance structure:
Size and shape: The overall shape is rectangular with some small cuts, and the specific size is not clearly disclosed.
Ports and Connections: Equipped with three female 37 pin ports and three male 37 pin connectors for connecting to TRPG boards. There are also two terminal blocks, with the first block labeled 1-24 and the second block labeled 25-48. In addition, there are two green 3-pin sockets and one white 4-pin socket. At the bottom corner, there are two reinforced terminal holes; At the top edge, there are four installation indentations and a small factory drill hole; On both sides near the top corner, there are two large factory boreholes.
Electronic components: There are two large transformers, eight red circular components, as well as many diodes, resistors, and capacitors on the circuit board.
Functional features:
System interface: Usually connected to the main turbine protection printed circuit board (VTUR), the TRPG (main trip terminal) board is controlled through PTUR components.
Application support: Able to support simplex and TMR (Triple Modular Redundancy) applications.
Precautions for use: When handling IS200TTURH1CCC, it is recommended to use anti-static procedures to ensure that no damage is caused by electrostatic impact. Before installation, the TTUR should be stored in anti-static packaging and an anti-static wristband should be used during installation.
