Part Number: 3BDH000002R1
Type: Base Unit / Terminal Base
Series: ABB S800 I/O
Mounting: DIN rail
Connection: Screw terminals for field wiring
Bus Interface: S800 I/O backplane bus
Operating Temperature: -25°C to +60°C
Protection: IP20
Dimensions: Standard S800 I/O base size
Weight: Approx. 0.15 kg
Condition: New / Surplus
Warranty: 1 Year
Description
ABB 3BDH000002R1 is a standard base unit designed for the ABB S800 I/O modular system. It provides physical mounting, electrical connection, and field wiring terminals for S800 I/O signal modules.
This base module acts as a mechanical and electrical interface between field devices and S800 I/O signal modules (AI, AO, DI, DO). It features screw terminals for secure field wiring, integrated bus connection to the I/O bus, and support for standard DIN rail mounting. It is widely used in ABB AC500, AC800M, 800xA DCS systems for process automation in oil & gas, power, and manufacturing industries.
